HDMI source → DisplayPort display
$56.99
active · USB-powered · 4K 30Hz maximum
Ships from a US warehouse in 5 days. Shipping to the United States is included. Shipping details.
One StarTech.com HD2DP active converter for connecting an HDMI source to one DisplayPort monitor or projector. The HDMI male plug carries video from the source, the DisplayPort female port accepts the display cable, and USB supplies power. It is not the common reverse-direction DisplayPort-to-HDMI adapter.
The measurement
HDMI source → DisplayPort display
active · USB-powered · 4K 30Hz maximum
The fit
Illustration based on the product photo. Use the measurements written on this page.
Active HDMI to DisplayPort 4K30 adapter is listed for active · usb-powered · 4k 30hz maximum. Compare every deciding measurement below with your space before ordering.
| Signal direction | HDMI source to DisplayPort display |
|---|---|
| Conversion | Active |
| Power | USB-powered; USB extension included |
| Maximum stated resolution | 3840 × 2160 at 30 Hz |
| HDCP 2.2 | Not supported |
| Video input | HDMI 1.4 male |
| Video output | DisplayPort 1.2 female |
| Additional stated mode | 1920 × 1080 at 120 Hz |
| Audio | Up to 7.1-channel |
| Product length | 10 in |
| Not reversible | Does not connect a DisplayPort source to an HDMI display |
| Not for | 4K 60Hz, HDCP 2.2-protected 4K playback, DisplayPort-to-HDMI conversion, or multiple displays |
Ships from a US warehouse in 5 days. Shipping to the United States is included.
You can return an unused item within 30 days of delivery. You pay the return postage. If the item arrives damaged, or it is a different measurement than the product page states, write to support@utiliy.com and Utiliy pays the return.
It is HDMI source to DisplayPort display. It is specifically for the less common reverse direction and is not interchangeable with a DisplayPort-to-HDMI adapter.
USB powers the active signal converter. The USB connection does not carry the video signal.
No. Its published 4K maximum is 3840 by 2160 at 30 Hz.
No. StarTech.com states that HD2DP does not support HDCP 2.2.
Connect the HDMI male plug to the source, a DisplayPort cable from the female DisplayPort output to the display, and USB to a powered USB port.
Utiliy transcribes published maker or supplier specifications into consistent units and does not fill in measurements that were not supplied.
