What is the vertical slot spacing on ClosetMaid ShelfTrack standards?
The adjustment pitch is 1.25 inches.
The measurement
12 or 30 in vertical standard
1.25 in slot pitch · 24 in maximum spacing · ShelfTrack
ClosetMaid ShelfTrack vertical standard
12 or 30 in vertical standard
$8.99
1.25 in slot pitch · 24 in maximum spacing · ShelfTrack
- Closet systemClosetMaid ShelfTrack
- Slot pitch1.25 in
- Maximum standard spacing24 in
- Maximum shelf-end setback4 in
Ships from a US warehouse in 3 to 4 days. Shipping to the United States is included. Shipping details.
A white steel ClosetMaid ShelfTrack double-slot vertical standard in 12-inch or 30-inch length. Both variants use 1.25-inch vertical adjustment increments, snap into a ShelfTrack hang track or mount to a suitable wall surface, and must be placed no more than 24 inches apart and no more than 4 inches from a shelf end.
The fit
12 or 30 in vertical standard
- Closet systemClosetMaid ShelfTrack
- Slot pitch1.25 in
- Maximum standard spacing24 in
- Maximum shelf-end setback4 in
Illustration based on the product photo. Use the measurements written on this page.
Measurements
ClosetMaid ShelfTrack vertical standard is listed for 1.25 in slot pitch · 24 in maximum spacing · shelftrack. Compare every deciding measurement below with your space before ordering.
| Closet system | ClosetMaid ShelfTrack |
|---|---|
| Slot pitch | 1.25 in |
| Maximum standard spacing | 24 in |
| Maximum shelf-end setback | 4 in |
| Cross-section | 1 × 0.625 in |
| Material | Steel with white epoxy finish |
| Mounting | ShelfTrack hang track or correctly fastened to studs, concrete or drywall |
| Not included | Hang track, shelf brackets and wall fasteners |
| Not for | ClosetMaid Fixed Mount hardware or unverified generic bracket geometries |
| Standard length | 12 in |
Product photos
Shipping and returns
Ships from a US warehouse in 3 to 4 days. Shipping to the United States is included.
You can return an unused item within 30 days of delivery. You pay the return postage. If the item arrives damaged, or it is a different measurement than the product page states, write to support@utiliy.com and Utiliy pays the return.
Fitment answers
How far apart can ShelfTrack standards be installed?
No more than 24 inches apart and no more than 4 inches from each shelf end.
Can a ShelfTrack standard mount without a hang track?
Yes, when it is fastened correctly for the wall surface. Hardware is not included.
Do these standards accept ClosetMaid Fixed Mount hardware?
No. They are part of the adjustable ShelfTrack system.
Which standard length should I choose?
Choose 12 inches for a short single-level adjustment zone or 30 inches when the shelf layout needs a taller vertical adjustment range.
Product data and verification
Utiliy transcribes published maker or supplier specifications into consistent units and does not fill in measurements that were not supplied.
